Product Details
Place of Origin: Shenzhen, China
Brand Name: ZKMANET
Certification: CE, ISO9001
Model Number: ZKManet1242T
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: USD 1999~2999
Packaging Details: Brown Carton
Delivery Time: 5~8 working days
Payment Terms: T/T, Western Union
Supply Ability: 10000 pieces per year
Frequency: |
300MHz-2.7GHz Customizable |
Modulation: |
COFDM |
Output Power: |
33dBm |
Bandwidth: |
2-8MHz |
Encryption: |
AES256 (user-defined) |
Video Input: |
HDMI/CVBS |
Video Compression: |
H.264 |
Dimensions: |
220*120*45(mm) |
Frequency: |
300MHz-2.7GHz Customizable |
Modulation: |
COFDM |
Output Power: |
33dBm |
Bandwidth: |
2-8MHz |
Encryption: |
AES256 (user-defined) |
Video Input: |
HDMI/CVBS |
Video Compression: |
H.264 |
Dimensions: |
220*120*45(mm) |
The ZKManet1242T is a lightweight and portable backpack transmitter, offering high-definition and stable image quality. Utilizing COFDM modulation technology, it enables the capture and real-time transmission of high-quality images even in non-line-of-sight conditions and during high-speed movement, while also encrypting images and data throughout the process. It can be paired with the ZKManet1002R receiver, making it particularly effective in complex environments with numerous obstacles. This device is ideal for public security, armed police operations, and major events requiring on-site security and emergency response efforts.
* Supports HDMl and AV dual video ports
* Aluminum alloy material, impact resistant
* Range up to 1.5-3km
* 10.1 inch high screen, Manpack design for easy operation
* COFDM modulation and H.264 compression
| Model | ZKManet1242T | ||
| RF Parameters | Frequency | Video: 300MHz-2.7GHz customizable; | |
| Audio: 145Mhz | |||
| Modulation | QPSK(4QAM)/16QAM/64QAM | ||
| Output Power | 2W | ||
| Bandwidth | 2-8MHz | ||
| Encryption | AES | ||
| Range | 1.5-3km | ||
| RF Interface | N-F | ||
| Video/Audio Parameters | Video Input | HD:HDMI | |
| SD:RCA | |||
| Video Modulation | HD:1080P,1080i,720P,720i | ||
| SD:P/N | |||
| Video Compression | H.264 | ||
| Physical/Environment | Dimensions | 220*120*45(mm) | |
| Weight | 1.3kg(w/ battery) | ||
| Working Temp | -20°C~ +65°C | ||
| Electronic Parameters | Power Supply | DC 12V | |
| Battery Capacity | 4500mAh | ||
| Power Consumption | <43dBm | ||
Zhongke Lianxun (Shenzhen) Technology Co., Ltd is a high-tech R&D enterprise. Our products mainly use Mesh, COFDM and LTE as core technologies and auxiliary decision-making software to form underground building emergency communication systems, and police investigation communication systems, and police noncombat training communication systems, urban emergency communication systems, emergency communication vehicle communication systems, etc. The products are widely used in law enforcement agencies and government departments such as public security, armed police, , forest fire prevention, civil air defense, and maritime affairs.
