Lightweight 45g FHSS UAV Radio Link for Drones

Name: Lightweight 45g FHSS UAV Radio Link for Drones
Brand: Zhongke Lianxun (Shenzhen) Technology Co., Ltd
SKU: ZKMANET3460-UAV
Price: 14999.00 USD
Availability: InStock

Product Details

Brand Name: ZKMANET

Certification: CE,FCC,ROHS

Model Number: ZKMANET3460-UAV

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 2

Packaging Details: Carton

Delivery Time: 5-15days

Payment Terms: TT

Supply Ability: 100000pcs/year

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                lightweight FHSS drone radio link, 45g UAV data link, FHSS drone communication system


Size:	564811mm	Nodes:	8 Nodes Customizable
Antenna Type:	Omni-directional	Frequency Hopping:	Support, 1000hops/s
Weight:	45g	Date Rate:	48Mbps(Max)
Modulation Type:	BPSK/QPSK/16QAM/64QAM (adaptive)	Antenna Gain:	2 DBi

Size:	564811mm
Nodes:	8 Nodes Customizable
Antenna Type:	Omni-directional
Frequency Hopping:	Support, 1000hops/s
Weight:	45g
Date Rate:	48Mbps(Max)
Modulation Type:	BPSK/QPSK/16QAM/64QAM (adaptive)
Antenna Gain:	2 DBi

Lightweight 45g FHSS UAV Radio Link for Drones

Lightweight Frequency Hopping Anti-Jamming Drone Data Link 45g FHSS UAV Radio Link

Key Specifications

Size	56×48×11mm
Nodes	8 Nodes Customizable
Antenna Type	Omni-directional
Frequency Hopping	Support, 1000hops/s
Weight	45g
Date Rate	48Mbps (Max)
Modulation Type	BPSK/QPSK/16QAM/64QAM (adaptive)
Antenna Gain	2 DBi

Product Overview

The Drone Data Link is a cutting-edge communication system designed specifically for UAV data transmission, providing reliable connectivity for drones in various applications.

With its compact dimensions of 56×48×11mm and lightweight 45g design, this data link integrates seamlessly into drones without adding significant weight or bulk. The omni-directional antenna ensures reliable connections from all angles, while the 2 DBi antenna gain boosts signal strength for stable operation in challenging environments.

Technical Parameters

HDMI Interface

Support

Application

Drone UAV Communication

Intelligent Frequency Selection

Support

RF Channel

2T2R

Output Power

Positioning

GPS/BD/GLONASS

Interface

LAN/TTL; HDMI

Applications

The ZKMANET3460-UAV system enhances communication between ground control stations and unmanned aerial vehicles across multiple industries:

Commercial and recreational drone operations
Agricultural monitoring and spraying
Construction site surveying
Surveillance and security applications
Industrial inspections
Aerial photography and videography

Customization Options

Brand Name

ZKMANET

Model Number

ZKMANET3460-UAV

Certification

CE, FCC, ROHS

Minimum Order Quantity

2 units

Delivery Time

5-15 days

Transmitter Range

20-49km (Customizable)

Frequencies

1350-1450MHz
