IP54 Drone Data Link with AES Encryption 5-40MHz Bandwidth

Name: IP54 Drone Data Link with AES Encryption 5-40MHz Bandwidth
Brand: Zhongke Lianxun (Shenzhen) Technology Co., Ltd
SKU: ZKMANET2451UM
Price: 1500 USD
Availability: InStock

Product Details

Place of Origin: Shenzhen

Brand Name: ZKMANET

Certification: CE

Model Number: ZKMANET2451UM

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: 1500USD/PC

Packaging Details: Carton

Delivery Time: 15days

Payment Terms: TT

Supply Ability: 10000pcs/year

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                IP54 Rated Drone Data Link, DC12-24V Drone Data Link, 5/10/20/40MHz Drone Data Link


Encryption:	AES	Data Rate:	30Mbps(MAX)
Type:	Drone MESH Video Link	Weight:	450g
Output Power:	4W	Bandwidth:	5/10/20/40MHz
IP Rating:	IP54	Power Supply:	DC12-24V

Encryption:	AES
Data Rate:	30Mbps(MAX)
Type:	Drone MESH Video Link
Weight:	450g
Output Power:	4W
Bandwidth:	5/10/20/40MHz
IP Rating:	IP54
Power Supply:	DC12-24V

IP54 Drone Data Link with AES Encryption 5-40MHz Bandwidth

IP54 Drone Data Link

5/10/20/40 MHz bandwidth, DC12-24 V, long-range transmission

Key Specifications

Encryption	AES
Data rate	30Mbps(MAX)
Type	Drone MESH Video Link
Weight	450g
Output power	4W
Bandwidth	5/10/20/40MHz
IP Rating	IP54
Power Supply	DC12-24V

Product Overview

With selectable bandwidths of 5/10/20/40 MHz, the Drone Data Link delivers high-quality, low-latency video, audio, and telemetry with exceptional accuracy. Its transmission range of up to 50 km (LOS) ensures wide-area coverage and a stable connection, even in challenging environments.

Equipped with AES encryption, it safeguards data against unauthorized access, making it ideal for security-critical applications such as military missions, border surveillance, and infrastructure protection.

The system consumes less than 12 W, enabling long-duration operations without frequent battery changes, while its -40 ℃ to +65 ℃ operating range and rugged construction ensure reliable performance in extreme conditions.

Key Features

Product Name: Drone Data Link
Output power: 4W
RF Channel: 2T2R
Interface: LAN/TTL;HDMI
Bandwidth: 5/10/20/40MHz
Encryption: AES

Technical Specifications

Product Name	Drone Communication and Data Transmission Link
Interface	LAN/TTL; HDMI
RF Channel	2T2R
Power consumption	<12W
Weight	450g
Frequency Band	300MHz-3.8GHz (Customizable)
Size	1209040mm
Bandwidth	5/10/20/40MHz
IP Rating	IP54
Working Temperature	-40℃- +65℃
Encryption	AES

Applications

The ZKMANET2451UM Drone MESH Video Link is suitable for a range of applications including aerial photography, surveying and mapping, search and rescue missions, wildlife and livestock monitoring, and security surveillance. It provides real-time video and data transmission between drones and ground stations.

Packaging Information

1 x Drone Data Link
1 x User Manual
1 x USB Cable
1 x Antenna

Shipping: Standard Shipping (5-7 business days), Free Shipping

Frequently Asked Questions

What is the brand name of the drone data link product?

The brand name is ZKMANET.

What is the model number?

The model number is ZKMANET2451UM.

Where is the product manufactured?

Manufactured in Shenzhen.

Is the product certified?

Yes, certified with CE.

What is the minimum order quantity?

Minimum order quantity is 1.

What is the price?

1500 USD/PC.
