Product Details
Place of Origin: Shenzhen
Brand Name: LINKAV
Certification: CE
Model Number: MANET3622-W
Payment & Shipping Terms
Minimum Order Quantity: 1
Packaging Details: Carton
Delivery Time: 15days
Payment Terms: TT
Supply Ability: 10000pcs/year
MANET3622-W
LinkAV
| Data Rate: | 30Mbps |
| Bandwidth: | 1.4/2.5/5/10/20/40MHz |
| RF Channel: | 1T2R |
| Size: | 103.5*61.5*22mm |
| LAN Interface: | RJ45*2,TTL*3 |
| Type: | Drone Video Link |
| Encryption: | AES128 |
The Drone Data Link features an IP65 rating for dust and water resistance, making it ideal for challenging environments like construction sites or outdoor events.
Triple frequency band operation: 800MHz, 1.4GHz, and 2.4GHz
Compact dimensions: 103.5×61.5×22mm
Lightweight design at just 142g
Multiple LAN interfaces: RJ45×2, TTL×3
RF Channel: 1T2R configuration
Adjustable bandwidth: 1.4/2.5/5/10/20/40MHz
Robust AES128 encryption
This versatile data link supports numerous professional applications:
Search and Rescue: Real-time video/audio transmission for critical decision-making
Agriculture: Crop health monitoring and precision farming
Construction: Site surveying and safety monitoring
Environmental Monitoring: Air/water quality assessment and wildlife tracking
Security: Public space and infrastructure surveillance
Delivery Systems: Remote area supply transport
