Mini Monocular Helmet Camera with 128G Memory and MESH WIFI 4G Bluetooth Network Supported

Name: Mini Monocular Helmet Camera with 128G Memory and MESH WIFI 4G Bluetooth Network Supported
Brand: Zhongke Lianxun (Shenzhen) Technology Co., Ltd
SKU: ZKManet9601
Price: 199.00 USD
Availability: InStock

Product Details

Place of Origin: Shenzhen, China

Brand Name: ZKMANET

Certification: CE, ISO9001

Model Number: ZKManet9601

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: USD 99~299

Packaging Details: Brown Carton

Delivery Time: 5~8 working days

Payment Terms: T/T, Western Union

Supply Ability: 10000 pieces per year

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                128G Memory Helmet Camera, MESH WIFI Helmet Camera, 4G Bluetooth Helmet Camera


OS:	Linux + Rtos	Memory:	Default 128GB (256GB Optional)
LED Indicator:	High Brightness LED	Video Resolution:	1080P
IP Rating:	IP67	Video Compression:	H.264/H.265
Working Time:	4.5h	Weight:	180g

OS:	Linux + Rtos
Memory:	Default 128GB (256GB Optional)
LED Indicator:	High Brightness LED
Video Resolution:	1080P
IP Rating:	IP67
Video Compression:	H.264/H.265
Working Time:	4.5h
Weight:	180g

Mini Monocular Helmet Camera with 128G Memory and MESH WIFI 4G Bluetooth Network Supported

The ZKManet9601 monocular helmet camera is a specialized device developed for the needs of single-person portable monitoring in scenarios such as armed police, special police, mobile law enforcement evidence collection, and administrative supervision. This product uses a high-speed processor and embedded Linux operating system, integrating ultra-low-light color cameras, audio, 4G and Wi-Fi wireless communication modules, GPS/Beidou, storage, alarm modules, and is equipped with high-definition night vision cameras and wireless Bluetooth headsets. The device can transmit real-time audiovisual information and support functions such as voice intercom through MESH self-organizing network single soldier, 4G, and Wi-Fi wireless networks.

* Support 4G
* Supports GPS/BD positioning
* Rugged IP67 housing
* Supports Wi-Fi
* Supports national standard video transmission

Basic Parameters	OS	Linux + rtos
	Memory	Default 128GB (256GB optional)
	LED Indicator	High brightness LED
	Interface	Type-C
Network Parameters	WI-FI	2.4G
	Bluetooth	Support
	4G	Support, micro slot
	GPS/BD	Support
Video/Audio Collection	Video Resolution	1080P
	Audio Input	2 channel (MIC/ Bluetooth earphone)
	Video Frame Rate	1080p@120fps/1080p@30fps/720p@30fps//720p@120fpsVGA@30fps/QVGA@30fps
	Video Compression	H.264/H.265
Physical/Environment	Dimensions	925343mm
	Weight	180g
	Working Temp	-20~60ºC
	IP Rating	IP67
Electrical Parameters	Battery Capacity	2800mAh
	Voltage	3.8V
	Working Time	>4.5h

Zhongke Lianxun (Shenzhen) Technology Co., Ltd is a high-tech R&D enterprise. Our products mainly use Mesh and LTE as core technologies and auxiliary decision-making software to form underground building emergency communication systems, and police investigation communication systems, and police noncombat training communication systems, urban emergency communication systems, emergency communication vehicle communication systems, etc., suitable for law enforcement forces and government departments such as public security, armed police, , forest fire prevention, civil air defense, and maritime. Especially the intelligent communication products of special robots have solved the long-distance communication and control problems of robots in complex environments.

We have multiple patents with independent intellectual property rights, has established a sound quality system and national standard system that comply with ISO9001 standards, and strictly produces products in accordance with national standards and internationally recognized standards such as CCC, CE, FCC, etc. It has obtained the Radio Transmission Equipment Model Approval Certificate issued by the Ministry of Industry and Information Technology of China and has passed the wireless product testing certification of the Ministry of Public Security.
